Tiny Tools

MGR Bars Grooving

B Min. K20
D Ordering Code L L1 H F a BXC BMK TNX Holder
mm in Dia.
MGR 6 B1.0 L15 51 15 1.0 .039 1.4 2.8 5.8 6.1 ● ● ● ●
MGR 6 B1.0 L22 51 22 1.0 .039 1.4 2.8 5.8 6.1 ● ● ● ●
MGR 6 B1.5 L15 51 15 1.5 .059 1.4 2.8 5.8 6.1 ● ● ● ●
6.0 SIM ... H6
MGR 6 B1.5 L22 51 22 1.5 .059 1.4 2.8 5.8 6.1 ● ● ●
MGR 6 B2.0 L15 51 15 2.0 .079 1.4 2.8 5.8 6.1 ● ● ● ●
MGR 6 B2.0 L22 51 22 2.0 .079 1.4 2.8 5.8 6.1 ● ● ● ●
MGR 6 B0.79 L17 51 17 0.79 .031 1.8 2.8 5.8 6.1 ● ● ●
MGR 6 B0.79 L23 51 23 0.79 .031 1.8 2.8 5.8 6.1 ● ● ●
MGR 6 B1.0 L17 51 17 1.0 .039 1.8 2.8 5.8 6.1 ● ● ●
MGR 6 B1.19 L17 51 17 1.19 .047 1.8 2.8 5.8 6.1 ● ● ●
MGR 6 B1.19 L23 51 23 1.19 .047 1.8 2.8 5.8 6.1 ● ● ●
6.0 MGR 6 B1.5 L17 51 17 1.5 .059 1.8 2.8 5.8 6.1 ● ● ● SIM ... H6
MGR 6 B1.5 L23 51 23 1.5 .059 1.8 2.8 5.8 6.1 ● ● ●
MGR 6 B1.59 L17 51 17 1.59 .063 1.8 2.8 5.8 6.1 ● ● ●
MGR 6 B1.59 L23 51 23 1.59 .063 1.8 2.8 5.8 6.1 ● ● ●
MGR 6 B2.0 L17 51 17 2.0 .079 1.8 2.8 5.8 6.1 ● ● ●
MGR 6 B2.0 L23 51 23 2.0 .079 1.8 2.8 5.8 6.1 ● ● ●
MGR 7 B1.0 L15 62 15 1.0 .039 2.5 3.3 6.8 7.1 ● ● ●
MGR 7 B1.0 L22 62 22 1.0 .039 2.5 3.3 6.8 7.1 ● ● ●
MGR 7 B1.0 L30 62 30 1.0 .039 2.5 3.3 6.8 7.1 ● ● ●
MGR 7 B1.19 L22 62 22 1.19 .047 2.5 3.3 6.8 7.1 ● ● ●
MGR 7 B1.19 L30 62 30 1.19 .047 2.5 3.3 6.8 7.1 ● ● ●
MGR 7 B1.5 L15 62 15 1.5 .059 2.5 3.3 6.8 7.1 ● ● ●
7.0 MGR 7 B1.5 L22 62 22 1.5 .059 2.5 3.3 6.8 7.1 ● ● ● SIM ... H7
MGR 7 B1.5 L30 62 30 1.5 .059 2.5 3.3 6.8 7.1 ● ● ●
MGR 7 B1.59 L22 62 22 1.59 .063 2.5 3.3 6.8 7.1 ● ● ●
MGR 7 B1.59 L30 62 30 1.59 .063 2.5 3.3 6.8 7.1 ● ● ●
MGR 7 B2.0 L15 62 15 2.0 .079 2.5 3.3 6.8 7.1 ● ● ●
MGR 7 B2.0 L22 62 22 2.0 .079 2.5 3.3 6.8 7.1 ● ● ●
MGR 7 B2.0 L30 62 30 2.0 .079 2.5 3.3 6.8 7.1 ● ● ●
MGR 8 B1.0 L22 64 22 1.0 .039 1.7 3.8 7.8 8.1 ● ● ●
MGR 8 B1.5 L22 64 22 1.5 .059 1.7 3.8 7.8 8.1 ● ● ● ●
MGR 8 B2.0 L15 64 15 2.0 .079 2.6 3.8 7.8 8.1 ● ● ●
8.0 MGR 8 B2.0 L22 64 22 2.0 .079 2.6 3.8 7.8 8.1 ● ● ● ● SIM ... H8
MGR 8 B2.38 L15 64 15 2.38 .094 2.6 3.8 7.8 8.1 ● ● ●
MGR 8 B2.38 L22 64 22 2.38 .094 2.6 3.8 7.8 8.1 ● ● ●
New
New MGR 8 B3.0 L30 64 30 3.0 .118 2.6 3.8 7.8 8.1 ● ● ●
New
Tolerance: B±0.025 mm/.001” ● Available.
Order example: MGR 5 B1.5 L15 BXC Other items available upon request
See pages 40-54 for holders
