Page 107 - Carmex - Inch Catalog 2018-19 Rev. B
P. 107
®
Tiny Tools
MZR Bars Face Grooving
D Min.
Ordering Code L L1 R W T F Holder*
mm Dia.
MZR 4 R0.5 L15 2.0 .59 .020 .04 .05 .08 .20
4.0 SIM ... H4
MZR 4 R0.75 L15 2.0 .59 .030 .06 .06 .08 .20
MZR 5 R0.5 L22 2.0 .87 .020 .04 .05 .10 .24
5.0 MZR 5 R0.75 L22 2.0 .87 .030 .06 .06 .10 .24 SIM ... H5
MZR 5 R1.0 L22 2.0 .87 .039 .08 .10 .10 .24
MZR 6 R0.5 L22 2.0 .87 .020 .04 .05 .12 .31
6.0 MZR 6 R0.75 L22 2.0 .87 .030 .06 .06 .12 .31 SIM ... H6
MZR 6 R1.0 L22 2.0 .87 .039 .08 .10 .12 .31
Order example: MZR 5 R0.5 L22 BXC
* For additional holders see pages 106-111
