Tiny Tools

MPR Bars Profiling and Boring

Grade P M K N S H
K20    
BXC      
BMK      
TNX      
For L.H. Bars specify MPL instead of MPR First choice Alternative

Min.
D Ordering Code L L1 R H F a K20 BXC BMK TNX Holder
Dia.
MPR 1 R0.05 L4 39 4 0.05 0.2 0.45 0.95 1.0   
3.0 SIM ... H3
MPR 1 R0.05 L8 39 8 0.05 0.2 0.45 0.95 1.0   
MPR 1.2 R0.1 L5 39 5 0.10 0.3 0.55 1.15 1.2   
3.0 SIM ... H3
MPR 1.2 R0.1 L9 39 9 0.10 0.3 0.55 1.15 1.2   
MPR 1.5 R0.05 L10 39 10 0.05 0.3 0.7 1.4 1.5   
3.0 MPR 1.5 R0.1 L6 39 6 0.10 0.3 0.7 1.4 1.5     SIM ... H3
MPR 1.5 R0.1 L10 39 10 0.10 0.3 0.7 1.4 1.5    
MPR 2 R0.05 L10 39 10 0.05 0.5 0.8 1.8 2.1   
MPR 2 R0.1 L10 39 10 0.10 0.5 0.8 1.8 2.1    
3.0
MPR 2 R0.15 L5 39 5 0.15 0.5 0.8 1.8 2.1     SIM ... H3
MPR 2 R0.15 L10 39 10 0.15 0.5 0.8 1.8 2.1    
MPR 2 R0.15 L15 39 15 0.15 0.5 0.8 1.8 2.1    
MPR 2.5 R0.1 L10 51 10 0.10 0.6 1.0 2.3 2.5   
4.0 SIM ... H4
MPR 2.5 R0.1 L15 51 15 0.10 0.6 1.0 2.3 2.5   
MPR 3 R0.05 L10 39 10 0.05 0.7 1.3 2.8 3.1    
MPR 3 R0.05 L15 39 15 0.05 0.7 1.3 2.8 3.1   
MPR 3 R0.1 L10 39 10 0.10 0.7 1.3 2.8 3.1   
MPR 3 R0.1 L15 39 15 0.10 0.7 1.3 2.8 3.1    
3.0 MPR 3 R0.1 L22 47 22 0.10 0.7 1.3 2.8 3.1    SIM ... H3
MPR 3 R0.2 L10 39 10 0.20 0.7 1.3 2.8 3.1    
MPR 3 R0.2 L15 39 15 0.20 0.7 1.3 2.8 3.1    
MPR 3 R0.2 L22 47 22 0.20 0.7 1.3 2.8 3.1    
MPR 4 R0.1 L10 51 10 0.10 0.8 1.7 3.8 4.1    
MPR 4 R0.1 L15 51 15 0.10 0.8 1.7 3.8 4.1    
MPR 4 R0.1 L22 51 22 0.10 0.8 1.7 3.8 4.1   
4.0 MPR 4 R0.2 L10 51 10 0.20 0.8 1.7 3.8 4.1     SIM ... H4
MPR 4 R0.2 L15 51 15 0.20 0.8 1.7 3.8 4.1    
MPR 4 R0.2 L22 51 22 0.20 0.8 1.7 3.8 4.1    
MPR 4 R0.2 L30 62 30 0.20 0.8 1.7 3.8 4.1   
See pages 40-54 for holders ● Available. Other items available upon request
