Page 162 - Carmex - Inch Catalog 2018-19 Rev. B
P. 162
®
Swiss-Line
Threading - UN unified 60°
External Thread Y X
Right Version L
Right hand cutting
L TPI Ordering Code X Y
72 GT19 R 72UN .11 .016
56 GT19 R 56UN .11 .024
40 GT19 R 40UN .11 .028
19
32 GT19 R 32UN .11 .028
24 GT19 R 24UN .11 .032
20 GT19 R 20UN .11 .039
Left hand cutting
L TPI Ordering Code X Y
72 GT19 L 72UN .11 .016
56 GT19 L 56UN .11 .024
40 GT19 L 40UN .11 .028
19
32 GT19 L 32UN .11 .028
24 GT19 L 24UN .11 .032
20 GT19 L 20UN .11 .039
156
