CMT Vertical Milling

Vertical milling indexable inserts and toolholders to perform a wide
variety of threads, grooves, chamfers and more.
Advantages of CMT - Vertical Milling

Ground profile inserts for high precision and Same insert for right-hand or left-hand threads.
excellent performance.
Toolholders include weldon shank and coolant
Working at high machining parameters, with high bore.
surface quality.
Chamfer inserts are also available.
Solid and accurate clamping method enables full
repeatability.

Contents: Page: Contents: Page:

Product Identification 210-211 Full Radius Groove Milling 223
Partial Profile 60˚ - UN, ISO 212-213 Face Milling and Finishing 223
Partial Profile 60˚ - NPT 213 Corner Rounding 224
Partial Profile 55˚ - BSW, BSF, BSP (G) 214 Steel Toolholders - with Coolant Bore 225
Full Profile - ISO 215-216 Carbide Shank Toolholders 226
Full Profile - UN 217-218 CMT Multi insert Milling Cutters 227
G 55˚ - BSW, BSF, BSP (G) 218 Product Identification 228
Trapez - DIN 103 219 Groove Milling 229
Acme 219 Groove Milling with Chamfer 230
Round - DIN 405 219 Partial Profile 60° - ISO, UN 231
Chamfering and Grooving 220 Toolholders 232
Chamfering, Grooving and Boring 220 Mill Cutter - Disc Milling 233
Groove Milling 221-222
