Page 140 - Carmex - Inch Catalog 2018-19 Rev. B
P. 140
®
Swiss-Line
Back Turning
B
R
W ß
T
H DETAIL A
α
Right hand cutting
K20 BLU
T Feed
Ordering Code ৠ᧠R W B H
max Inch/rev P
GB25 R A30 R03 30 15 .001 .118 .157 .020 .315 .002-.005 M
GB25 R A30 R10 30 15 .004 .118 .157 .020 .315 .002-.005 K
N
* For L.H, specify GB25 L instead of GB25 R
S
H ≤45 HRc
Front Turning
R
T
Right hand cutting
T Feed
Ordering Code R
max Inch/rev
GF25 R T40 .157 .002 .002-.005
* For L.H, specify GF25 L instead of GF25 R
First choice Alternative
134
