Mini Tools
Vertical Inserts and Toolholders for threading, chamfering, grooving
and turning
Advantages
Carbide grade: BLU-Sub-micron grade with advanced PVD triple layer coating delivering high heat
resistance and smooth cutting operation.
Carbide shank toolholder provides excellent Through coolant.
vibration resistance. For threading, grooving, boring and chamfering.
Long reach. Quick indexing.
Typical Applications:
Long threads or applications requiring over-hang.
Enables production of threads with large pitch/profile.
Threading, grooving, boring, profiling and chamfering - It’s
possible to offer most of the Tiny Tools profiles on the insert.
Contents: Page: Contents: Page:
Product Identification 118 Back Turning 122
Partial Profile 60° 119 Boring and Profiling 123
Partial Profile 55° 119 Boring, Profiling and Facing 123
ISO 120 Face Grooving 124
UN 120 Face Grooving Full Radius 125
Chamfering 121 Carbide Shank Toolholder 126
Grooving 121 Steel Toolholders 127
Full Radius Grooving 122 Technical Section 128
