Page 324 - Carmex - Inch Catalog 2018-19 Rev. B
P. 324
®
Supercut Roughers
CMT Roughers
Indexable CMT roughers for excellent performance
Solid and accurate clamping method enables full repeatability
Working at high machining parameters
Modular system using the standard CMT tool holders with various shank options
Enables machining with large overhang
Carbide Grade: CR3
w CHx45˚
Cutting Diameter
D
P M K N S H
≤56 HRc
Insert No. of
Type Ordering Code D Flutes W CH
S20 CRM160 F W50 .63 6 .197 .016
S20 CRM170 F W50 .67 6 .197 .016
S20 CRM200 F W50 .79 6 .197 .016
First choice Alternative
The CMT Roughers should be used with all the toolholders shown on page 318.
8 318
